The ASTM A182 GR F5 Flange is made according to the ASTM A182 standard. Its dimensions follow ANSI, ASME, and DIN standards. These flanges come in sizes ranging from ½ inch to 36 inches in nominal bore size. Delta Steel is a top supplier and manufacturer, offering a wide range of sizes and types.

ASTM A182 GR F5 Flange

Alloy Steel F5 Flanges

Alloy Steel ASTM A182 F5 Blind Flanges

Check SA 182 Gr F5 Steel Flanges, A182 F5 Cl1 Forged Flanges suppliers, 4340 Alloy Steel A182 Grade F5 slip on Flanges Dimension

The weight of ASME SA182 F5 pipe flanges depends on their wall thickness and bore size. The wall thickness is determined by the pressure class, which ranges from 150 to 2500 and PN6 to PN64. Alloy Steel F5 flanges are also available in different face types, including flat face, raised face, and ring-type joint.

Different flange types are designed for various connections, each offering its own benefits. Alloy Steel ASTM A182 F5 Blind Flanges are used to seal pipelines with either welded or bolted connections. Blind flanges are the only type that completely close off a pipeline. Other types of SA 182 Gr F5 Steel Flanges help extend and develop the pipeline. These flanges come in welded, seamless, and forged varieties, with the main differences being strength, durability, and toughness. The A182 F5 Cl1 Forged Flanges are made from a single piece of material, making them more durable and strong at connection points. Contact us for more information on the 4340 Alloy Steel A182 Grade F5 slip-on flanges, other flange types, and pricing details.

ASME SA182 F5 Pipe Flanges Specification Format

ASTM Specifications ASTM A182 and ASME SA182
Dimensions Chart ANSI/ASME B16.5, BS4504, BS 10, B 16.47 Series A & B, B16.48, EN-1092, DIN, etc.
Standard Flanges ANSI, ASME, BS, DIN, EN Flange, etc.
Size inch 1/2 inch to 36 inch
Class / Pressure Rating 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64
Type of Flange Face Flate, Raised Face, Ring Type Joint

Check DN15-1200 3000lbs A182 F5 Cl.2 RTJ Flange, SA182 F5 Plate Flange Price List, CNC machining SA 182 Gr F5 Socket Weld Flanges in India

Chemical Properties of Alloy Steel F5 Flanges

Grade C Mn Si S P Cr Mo
A182 F5 0.15 0.3 – 0.6 0.5 0.03 0.03 4 – 6 0.044 – 0.65

Mechanical Properties of Alloy Steel ASTM A182 F5 Blind Flanges

Grade Tensile Strength (Mpa) Yield Strength (Mpa) Elongation %
A182 F5 275 485 20

A182 F5 Cl1 Forged Flanges Size In Inch

Products Size
ASTM A182 F5 Slip-On Flange F5 Threaded Flanges Sizes 1/8 inch – 36 inch Raised or Flat Face
Alloy Steel Grades F5 Forged Flange Low Alloy Steel F5 Orifice Flange
ASTM A182 F5 Alloy Steel RTJ Flange ASTM A182 Grade F5 Pipe Flange
ASTM A182 Gr F5 Socket Weld Flange ASTM A182 Grade F5 Weld Weld Flange
ASTM A182 Grade F5 Plate Flange ASTM A182 Gr F5 Blind Flange
Grade F5 ASTM A182 Flange ASTM A182 F5 Lap Joint Flange
#150 ANSI Alloy Steel A182 F5 Cl2 Lap Joint Flange, 1cr-1/2mo Alloy Steel A182 F5 Flange stock, view ASME SA182 F5 Pipe Flange Weight chart

Weight Chart Of 4340 Alloy Steel A182 Grade F5 slip on Flanges

Pipe Normal Diam. O.D. Flange Thk. Of Flange Min Diam. of Hub Diameter of Raised Face Length Hub.Y Thread Length Diam. of Bolt Circle Diam. of Bolt Holes Number of Bolts Diam. of Bolts (inch) KG LB
inch dn O C X G Y T BC BH BN BD
1/2″ 15 89.00 11.20 30.20 35.10 15.70 15.70 60.50 15.80 4 1/2″ 0.4 0.9
3/4″ 20 98.50 12.70 38.10 42.90 15.70 15.70 69.90 15.80 4 1/2″ 0.7 1.5
1″ 25 108.00 14.20 49.30 50.80 17.50 17.50 79.30 15.80 4 1/2″ 0.8 1.8
1-1/4″ 32 117.50 15.70 58.70 63.50 20.60 20.60 88.90 15.80 4 1/2″ 1.2 2.6
1-1/2″ 40 127.00 17.50 65.00 73.20 22.40 22.40 98.60 15.80 4 1/2″ 1.5 3.3
2″ 50 152.50 19.10 77.70 91.90 25.40 25.40 120.70 19.10 4 5/8″ 2.3 5.1
2-1/2″ 65 178.00 22.40 90.40 104.60 28.40 28.40 139.70 19.10 4 5/8″ 3.7 8.1
3″ 80 190.50 23.90 108.00 127.00 30.20 30.20 152.40 19.10 4 5/8″ 4.1 9
3-1/2″ 90 216.00 23.90 122.20 139.70 31.80 31.80 177.80 19.10 8 5/8″ 5.1 11.2
4″ 100 228.50 23.90 134.90 157.20 33.30 33.30 190.50 19.10 8 5/8″ 5.9 13
5″ 125 254.00 23.90 163.60 185.70 36.60 36.60 215.90 22.40 8 3/4″ 7 15.4
6″ 150 279.50 25.40 192.00 215.90 39.60 39.60 241.30 22.40 8 3/4″ 8.4 18.5
8″ 200 343.00 28.40 246.10 269.70 44.50 44.50 298.50 22.40 8 3/4″ 13 28.6
10″ 250 406.50 30.20 304.80 323.90 49.30 49.30 362.00 25.40 12 7/8″ 18 39.5
12″ 300 482.50 31.80 365.30 381.00 55.60 55.60 431.80 25.40 12 7/8″ 29 64
14″ 350 533.50 35.10 400.10 412.80 57.20 57.20 476.30 28.50 12 1″ 39 86
16″ 400 597.00 36.60 457.20 469.90 63.50 63.50 539.80 28.50 16 1″ 47 103
18″ 450 635.00 39.60 505.00 533.40 68.30 68.30 577.90 31.80 16 1 1/8″ 57 126
20″ 500 698.50 42.90 558.80 584.20 73.20 73.20 635.00 31.80 20 1 1/8″ 76 167
24″ 600 813.00 47.80 663.40 692.20 82.60 82.60 749.30 35.10 20 1 1/4″ 97 214


SA182 F5 Plate Flange Prices

Alloy Steel ASTM A182 F5 Pipe Flange Price Per Piece in IndiaASTM A182 Gr F5 Flange Price in INRASTM A182 Gr F5 Flange Price in UAE Dirham
4″ WN RF CLASS 300, ASTM A182 GRADE F5, SCHEDULE 80, ASME B16.5Rs. 891.13UAE Dirham 45.64
3/4″ SW RF CLASS 300, ASTM A182 GRADE F5, SCHEDULE 80, ASME B16.5Rs. 689.32UAE Dirham 35.45
2″ SW RF CLASS 300, ASTM A182 GRADE F5, SCHEDULE 80, ASME B16.5Rs. 354.65UAE Dirham 18.24
1-1/2″ X 9″ LWN RF CLASS 300, ASTM A182 GRADE F5, SCHEDULE 80, ASME B16.5Rs. 976.98UAE Dirham 50.24
