ASTM A182 F11 Flange Manufacturer
Alloy Steel F11 Flanges, 1cr-1/2mo Alloy Steel A182 F11 Blind Flanges Manufacturer in Mumbai, India
The ASTM A182 F11 Flange is made for pressure vessels. These flanges come in different sizes, from ½ inch to 48 inches, depending on the flange standard. Delta Steel is a top supplier and manufacturer, offering Alloy Steel F11 Flanges in various types and sizes.
Check online Low Alloy Steel ASTM A182 F11 Flanges, ASTM A182 Grade F11 Slip on Flanges prices, Check Weight Chart of AS A182 F11 RTJ Flanges
There are different types of flanges like weld neck, socket weld, blind, ring type joint, and lap joint flanges. The 1Cr-1/2Mo Alloy Steel A182 F11 Blind Flanges are used to close a pipeline. This material contains carbon, manganese, silicon, phosphorus, chromium, and molybdenum. These flanges have a tensile strength of 415 MPa and a yield strength of 205 MPa.
The ASTM A182 F11 Low Alloy Steel Flanges are commonly used in welding applications. These flanges, also known as carbon steel flanges, come in different types, each serving specific purposes. For example, ASTM A182 Grade F11 Slip-on Flanges are used to connect two seamless pipes at a precise location, allowing the pipes to slip onto the flange for easy alignment. Another type is the ASTM A182 F11 RTJ Flanges, which come in two halves. These are welded or bolted together after being attached to the pipe ends, completing the connection. For more details on the A182 F11 Cl2 Weld Neck Flanges, other flange types, and pricing, feel free to contact us.
Material Specification Chart of Alloy Steel F11 Flanges
| ASTM Specifications | ASTM A182 and ASME SA182 |
| Dimensions Chart | ANSI/ASME B16.5, BS4504, BS 10, B 16.47 Series A & B, B16.48, EN-1092, DIN, etc. |
| Standard Flange | ANSI, ASME, BS, DIN, EN Flange, etc. |
| Size inch | 1/2 inch to 36 inch |
| Class / Pressure Rating | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 |
| Type of Flange Face | Flate, Raised Face, Ring Type Joint |
Prime quality Asme Sa182 F11 Class 2 Flange , Sa182 F11 Pipe Flange, View Astm A182 Alloy Steel F11 Flange Dimension & Pressure Rating
1cr-1/2mo Alloy Steel A182 F11 Blind Flanges Pressure Table
| Temperature Ratrings | 150# Class | 300# Class | 400# Class | 600# Class | 900# Class | 1500# Class | 2500# Class |
|---|---|---|---|---|---|---|---|
| -29 to 38 | 15.9 | 41.4 | 55.2 | 82.7 | 124.1 | 206.8 | 344.7 |
| 50 | 15.3 | 40 | 53.4 | 80 | 120.1 | 200.1 | 333.5 |
| 100 | 13.3 | 34.8 | 46.4 | 69.6 | 104.4 | 173.9 | 289.9 |
| 150 | 12 | 31.4 | 41.9 | 62.8 | 94.2 | 157 | 261.6 |
| 200 | 11.2 | 29.2 | 38.9 | 58.3 | 87.5 | 145.8 | 243 |
| 250 | 10.5 | 27.5 | 36.6 | 54.9 | 82.4 | 137.3 | 228.9 |
| 300 | 10 | 26.1 | 34.8 | 52.1 | 78.2 | 130.3 | 217.2 |
| 325 | 9.3 | 25.5 | 34 | 51 | 76.4 | 127.4 | 212.3 |
| 350 | 8.4 | 25.1 | 33.4 | 50.1 | 75.2 | 125.4 | 208.9 |
| 375 | 7.4 | 24.8 | 33 | 49.5 | 74.3 | 123.8 | 206.3 |
| 400 | 6.5 | 24.3 | 32.4 | 48.6 | 72.9 | 121.5 | 202.5 |
| 425 | 5.5 | 23.9 | 31.8 | 47.7 | 71.6 | 119.3 | 198.8 |
| 450 | 4.6 | 23.4 | 31.2 | 46.8 | 70.2 | 117.1 | 195.1 |
Thickness Chart Of ASTM A182 Grade F11 Slip on Flanges
| Pipe Normal Diam. | O.D. Flange | Thk. Of Flange Min | Diam. of Hub | Diameter of Raised Face | Length Hub.Y | Thread Length | Diam. of Bolt Circle | Diam. of Bolt Holes | Number of Bolts | Diam. of Bolts (inch) | KG | LB | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| inch | dn | O | C | X | G | Y | T | BC | BH | BN | BD | ||
| 1/2″ | 15 | 89.00 | 11.20 | 30.20 | 35.10 | 15.70 | 15.70 | 60.50 | 15.80 | 4 | 1/2″ | 0.4 | 0.9 |
| 3/4″ | 20 | 98.50 | 12.70 | 38.10 | 42.90 | 15.70 | 15.70 | 69.90 | 15.80 | 4 | 1/2″ | 0.7 | 1.5 |
| 1″ | 25 | 108.00 | 14.20 | 49.30 | 50.80 | 17.50 | 17.50 | 79.30 | 15.80 | 4 | 1/2″ | 0.8 | 1.8 |
| 1-1/4″ | 32 | 117.50 | 15.70 | 58.70 | 63.50 | 20.60 | 20.60 | 88.90 | 15.80 | 4 | 1/2″ | 1.2 | 2.6 |
| 1-1/2″ | 40 | 127.00 | 17.50 | 65.00 | 73.20 | 22.40 | 22.40 | 98.60 | 15.80 | 4 | 1/2″ | 1.5 | 3.3 |
| 2″ | 50 | 152.50 | 19.10 | 77.70 | 91.90 | 25.40 | 25.40 | 120.70 | 19.10 | 4 | 5/8″ | 2.3 | 5.1 |
| 2-1/2″ | 65 | 178.00 | 22.40 | 90.40 | 104.60 | 28.40 | 28.40 | 139.70 | 19.10 | 4 | 5/8″ | 3.7 | 8.1 |
| 3″ | 80 | 190.50 | 23.90 | 108.00 | 127.00 | 30.20 | 30.20 | 152.40 | 19.10 | 4 | 5/8″ | 4.1 | 9 |
| 3-1/2″ | 90 | 216.00 | 23.90 | 122.20 | 139.70 | 31.80 | 31.80 | 177.80 | 19.10 | 8 | 5/8″ | 5.1 | 11.2 |
| 4″ | 100 | 228.50 | 23.90 | 134.90 | 157.20 | 33.30 | 33.30 | 190.50 | 19.10 | 8 | 5/8″ | 5.9 | 13 |
| 5″ | 125 | 254.00 | 23.90 | 163.60 | 185.70 | 36.60 | 36.60 | 215.90 | 22.40 | 8 | 3/4″ | 7 | 15.4 |
| 6″ | 150 | 279.50 | 25.40 | 192.00 | 215.90 | 39.60 | 39.60 | 241.30 | 22.40 | 8 | 3/4″ | 8.4 | 18.5 |
| 8″ | 200 | 343.00 | 28.40 | 246.10 | 269.70 | 44.50 | 44.50 | 298.50 | 22.40 | 8 | 3/4″ | 13 | 28.6 |
| 10″ | 250 | 406.50 | 30.20 | 304.80 | 323.90 | 49.30 | 49.30 | 362.00 | 25.40 | 12 | 7/8″ | 18 | 39.5 |
| 12″ | 300 | 482.50 | 31.80 | 365.30 | 381.00 | 55.60 | 55.60 | 431.80 | 25.40 | 12 | 7/8″ | 29 | 64 |
| 14″ | 350 | 533.50 | 35.10 | 400.10 | 412.80 | 57.20 | 57.20 | 476.30 | 28.50 | 12 | 1″ | 39 | 86 |
| 16″ | 400 | 597.00 | 36.60 | 457.20 | 469.90 | 63.50 | 63.50 | 539.80 | 28.50 | 16 | 1″ | 47 | 103 |
| 18″ | 450 | 635.00 | 39.60 | 505.00 | 533.40 | 68.30 | 68.30 | 577.90 | 31.80 | 16 | 1 1/8″ | 57 | 126 |
| 20″ | 500 | 698.50 | 42.90 | 558.80 | 584.20 | 73.20 | 73.20 | 635.00 | 31.80 | 20 | 1 1/8″ | 76 | 167 |
| 24″ | 600 | 813.00 | 47.80 | 663.40 | 692.20 | 82.60 | 82.60 | 749.30 | 35.10 | 20 | 1 1/4″ | 97 | 214 |
AS A182 F11 RTJ Flange Sizes In Mm
| Pipe Size – Pipe Flange | Flange Connection Type | Max. Pressure |
|---|---|---|
| 1/2″ | FNPT | 150 psi |
| 1/2″ | Socket Weld | 275 psi |
| 1/2″ | Welded | 150 psi |
| 3/4″ | FNPT | 150 psi |
| 3/4″ | Socket Weld | 275 psi |
| 1-1/4″ | Socket Weld | 275 psi |
| 1-1/2″ | Socket Weld | 275 psi |
| 2″ | FNPT | 150 psi |
| 2″ | Socket Weld | 275 psi |
| 2-1/2″ | Socket Weld | 275 psi |
| 3″ | Socket Weld | 275 psi |
| 4″ | FNPT | 150 psi |
| 4″ | Socket Weld | 275 psi |
| 1/2″ | Slip On | 720 psi |
| 1/2″ | Slip On | 720 psi |
| 1″ | Slip On | 720 psi |
| 1″ | Slip On | 720 psi |
| 1-1/4″ | FNPT | 720 psi |
| 1-1/4″ | Slip On | 720 psi |
| 1-1/2″ | Slip On | 720 psi |
| 1-1/2″ | Slip On | 720 psi |
| 2″ | Slip On | 720 psi |
| 2″ | Slip On | 720 psi |
| 2-1/2″ | Slip On | 720 psi |
| 2-1/2″ | Slip On | 720 psi |
| 3″ | Slip On | 720 psi |
| 3″ | Slip On | 720 psi |
| 4″ | Slip On | 720 psi |
| 4″ | Slip On | 720 psi |
Astm A182 Grade F11 Class 2 Loose Flange in Mumbai, Sa182 Grade F11 Threaded Flange, View A182 F11 Cl2 Weld Neck Flange composition
Composition Chart of A182 F11 Cl2 Weld Neck Flanges
| Grade | C | Mn | Si | S | P | Cr | Mo |
| ASTM A182 F11 | 0.05 – 0.15 | 0.3 – 0.6 | 0.5 – 1 | 0.03 | 0.03 | 1 – 1.5 | 0.044 – 0.65 |
Asme Sa182 F11 Class 2 Flange Mechanical Properties Chart
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| ASTM A182 F11 Flange | 205 | 415 | 20 |
Sa182 F11 Pipe Flanges Prices
| ASTM A182 Grade F11 Class 2 Pipe Flange Price Per Piece in India | ASME SA182 Gr F11 Flange Price in INR | SA182 F11 Pipe Flange Price in UAE Dirham |
| 6 Inch Pipe ASTM 182 F11 Threaded Flange Price in India | Rs. 107.65 | UAE Dirham 5.51 |
| ASTM A182 F11 Flange Ansi 600lb F11 SCH80 ASTM A182 ASME B16.5 WN Price in India | Rs. 172.24 | UAE Dirham 8.81 |
| WN Flange 6 Inch ASTM A182 Gr F11 CL2 RF 1500# ASME B16.5 Price List | Rs. 14353.10 | UAE Dirham 734.23 |
| Price of ASTM A182 F11 8 in SCH160 CLASS 900 RTJ SW alloy flange in Mumbai | Rs. 15070.76 | UAE Dirham 770.94 |
| Blind Flange 8 Inch 600# Astm A182 F11 CL2 RF ASME B16.5 Cost in Mumbai | Rs. 16506.07 | UAE Dirham 844.37 |
